KMD.46 Aluminum windows and doors without thermal breaks

The KMD.46 system is a modern solution with high technical specifications, consisting of shaped aluminum profiles. It is designed for the manufacture of elements for external and internal construction that do not require thermal insulation, such as:
windows,
balcony and entrance doors,
spatial structures, and others.

The coating is available in various RAL colors with different effects: glossy, matte, "orange peel", metallic, and others.

Key Features:
Window system: basic depth of the frame — 46 mm, sash — 54.4 mm, ensuring a uniform surface on the exterior after closing.
Door system: depth — 46 mm, the frame and sash form a unified surface both inside and outside.

Filling and Sealing:
Insulated glazing units and other fillings are mounted on plastic supports and sealed with EPDM gaskets (ethylene-propylene-diene-monomer), which are waterproof and wear-resistant.
The filling is fixed with special glazing beads through an internal wedge gasket, allowing the use of fillings from 4 mm to 28 mm.

Installation and Connection:
Corner connections are made with special corner connectors, inserted into the internal chambers of the profiles. Fixing can be done by pressing or with stainless steel pins.
The attachment of transoms is done using "T-connectors", which allows the profiles to be connected at right angles.

Technical characteristics
